OB3398ETAP-H

Flyback AC-DC DIP-8 LED Drivers ICs

DIP-8RoHSActive

High Precision Offline LED Power Switch

Manufacturer: OB
Manufacturer part #: OB3398ETAP-H
Store part #: C7428780
Package / case: DIP-8
Category: LED Drivers ICs
Packaging: Tube-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,878 in stock

#C7428780

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹38.92	₹38.92
10+	₹33.54	₹335.40
50+	₹31.34	₹1,567.00
100+	₹28.55	₹2,855.00
500+	₹27.35	₹13,675.00
1,000+	₹26.55	₹26,550.00

Quantity (min 1)

1 × ₹38.92

₹38.92

excl. GST

₹45.93 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 50 per tube

OB3398ETAP-H

₹38.92 for 1 + GST

Specifications

Features: Over-Temperature Protection (OTP)
Switch Tube (Built-In/External): Built-in
Voltage - Input(AC): 90VAC~264VAC
Operating temperature: -40℃~+85℃
Topology: Flyback
Type: AC-DC

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tube-packed
Standard pack: 50 / Tube
Sold per: Piece
Minimum order: 1
Unit weight: 0.89 g

Overview

OB3398Ex is a primary side regulation off-line LED lighting power switch which can achieve accurate LED current. It significantly simplifies LED lighting system design by eliminating the secondary side feedback circuitry. Proprietary Constant Voltage (CV) and Constant Current (CC) control is integrated. The LED current (CC control) can be adjusted externally by the resistor Rs at CS pin. OB3398Ex offers comprehensive protection coverage with auto-recovery features including Cycle-by-Cycle current limiting, VDD clamp and UVLO.
