OC5031B OCX
OCX

OC5031B

LED Driver IC 1 Output Buck PWM Analog Dimming 10A SOT-23-6

SOT-23-6ROHS CompliantActive

High-end current-sensing step-down LED constant-current driver

Manufacturer
OCX
Manufacturer part #
OC5031B
Store part #
C2988400
Package / case
SOT-23-6
Category
LED Drivers ICs
Packaging
Tape & Reel (TR)
Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

10,010 in stock

#C2988400

Stock & price checked 6 days ago

QuantityUnit pricePack price
5+₹18.22₹91.10
50+₹14.88₹744.00
150+₹13.22₹1,983.00
500+₹11.97₹5,985.00
3,000+₹10.97₹32,910.00
6,000+₹10.48₹62,880.00

5 × ₹18.22

₹91.10

excl. GST

₹107.50 incl. 18% GST

Need volume or a scheduled delivery? Request a quote
  • Dispatch in 7–10 working days
  • GST invoice with every order
  • Standard pack: 3,000 per reel

OC5031B

₹91.10 for 5 + GST

Specifications

Features
Over-Temperature Protection (OTP)
Frequency - Switching
1MHz
Switch Tube (Built-In/External)
External
Operating temperature
-40℃~+85℃
Topology
Buck
Number of Channels
1
Output Current
10A
Voltage - Input(DC)
5.5V~60V
Constant Current Accuracy
3%

Packaging & compliance

RoHS
ROHS Compliant
Lifecycle
Active
Packaging
Tape & Reel (TR)
Standard pack
3,000 / Reel
Sold per
Piece
Minimum order
5 (multiples of 5)
Unit weight
0.05 g

Overview

Applications

  • Architectural, industrial, and environmental lighting
  • MR16 and LED lamps
  • Automotive lighting

Key features

  • Maximum output current: 10A
  • High efficiency: 96%
  • High-side current sensing
  • PWM dimming and linear dimming support
  • Hysteretic control, no loop compensation required
  • Maximum operating frequency: 1MHz
  • Current accuracy: ±3%
  • Wide input voltage range: 5.5V~60V
  • Over-temperature protection
  • High stability maintained during low dropout operation
