PAM2421AECADJR
520kHz Boost Adjustable 1.262V~24V 3A SOIC-8-EP Voltage Regulators - DC DC Switching Regulators RoHS
SOIC-8-EPROHS3 CompliantActive
3A, 4.5A, 5.5A PWM Step-Up DC-DC Converter
- Manufacturer
- DIODES
- Manufacturer part #
- PAM2421AECADJR
- Store part #
- C500792
- Package / case
- SOIC-8-EP
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,373 in stock
#C500792
Stock & price checked 40 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹96.86 | ₹96.86 |
| 10+ | ₹80.39 | ₹803.90 |
| 30+ | ₹73.45 | ₹2,203.50 |
| 100+ | ₹64.79 | ₹6,479.00 |
| 500+ | ₹60.90 | ₹30,450.00 |
| 1,000+ | ₹58.50 | ₹58,500.00 |
1 × ₹96.86
₹96.86
excl. GST
₹114.29 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
PAM2421AECADJR
₹96.86 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃
- Frequency - Switching
- 520kHz
- Function
- Boost
- Number of Outputs
- 1
- Features
- Adjustable soft-start;Cycle-by-cycle current limiting;Overcurrent Protection;Light load efficient mode
- Output Type
- Adjustable
- Topology
- Boost
- Operating Voltage
- 2.7V~5.5V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 1.262V~24V
- Output Current
- 3A
- Quiescent Current
- 200uA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.293 g
Overview
The PAM242x devices are high-performance, fixed frequency, current-mode PWM step-up DC/DC converters that incorporate internal power MOSFETs. The PAM242x includes an integrated power MOSFET that supports peak currents of up to 3A/4.5A/5.5A. The PAM242x utilizes simple external loop compensation allowing optimization between component size, cost and AC performance across a wide range of applications. Additional functions include an externally programmable soft-start function for easy inrush current control, internal over-voltage protection (OVP), cycle-by-cycle current limit protection, under voltage lock-out and thermal shutdown. The PAM242x is available in the small SOP-8(EP) package.
Applications
- TFT LCD Monitors
- Battery-Powered Equipment
- Set-Top Boxes DSL and Cable Modems and Routers
Key features
- Greater than 90% Efficiency
- Adjustable Output Voltage Up to 24V
- Internal 24V Power MOSFET
- Peak Current 3A,4.5A,5.5A
- 520kHz Frequency
- Built-in Over-Voltage Protection (OVP)
- Open Protection
- Programmable Soft-Start Function
- Thermal Shutdowns
- Under-Voltage-Lockout
- Over-Current Protection
- SOP-8(EP) Package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PAM2423AECADJR#C781891DIODES · ESOP-8 | DIODES | ESOP-8 | 4,527 | ₹94.96 · 4,527 in stock | View |
 | SLM6240AB-13GTR#C2988067Sillumin · SOIC-8-EP | Sillumin | SOIC-8-EP | 1,760 | ₹23.44 · 1,760 in stock | View |
