NexperiaDatasheet (PDF)
PESD1IVN24A-QX
42VC Clamp TVS DIODE SOT-323
SOT-323ROHS3 CompliantActive
TVS DIODE 24VWM 33VC SOT-323
- Manufacturer
- Nexperia
- Manufacturer part #
- PESD1IVN24A-QX
- Store part #
- C7025655
- Package / case
- SOT-323
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,570 in stock
#C7025655
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.79 | ₹68.95 |
| 50+ | ₹10.82 | ₹541.00 |
| 150+ | ₹9.34 | ₹1,401.00 |
| 500+ | ₹8.24 | ₹4,120.00 |
| 3,000+ | ₹7.36 | ₹22,080.00 |
| 6,000+ | ₹6.91 | ₹41,460.00 |
5 × ₹13.79
₹68.95
excl. GST
₹81.36 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PESD1IVN24A-QX
₹68.95 for 5 + GST
Specifications
- Clamping Voltage
- 33V
- Peak Pulse Current (Ipp)
- 3.5A@8/20us
- Voltage - Breakdown
- 25.5V
- type
- TVS
- Reverse Leakage Current (Ir)
- 1nA
- Reverse Stand-Off Voltage (Vrwm)
- 24V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.03 g
Overview
ESD protection device in a small SOD323 (SC-76) Surface-Mounted Device (SMD) plastic package designed to protect automotive in-vehicle network bus lines from the damage caused by ElectroStatic Discharge (ESD) and other transients.
Applications
- ESD protection for In - vehicle network lines in automotive environments
- CAN
- LIN
- FlexRay
- SENT
Key features
- Reverse stand-off voltage: VRWM = 24 V
- Low clamping voltage: VCL = 33 V at IPP = 3.5 A
- ESD protection up to 30 kV (IEC 61000 - 4 - 2)
- ESD protection up to 30 kV (ISO 10605: C = 330 pF, R = 330 Ω)
- ISO 7637 - 3: Pulse a: VS = -150 V / Pulse b: VS = +100 V
- Ultra low leakage current: |IRM| < 1 nA
- Qualified according to AEC - Q101 and recommended for use in automotive applications
