NexperiaDatasheet (PDF)
PESD1IVN27-UX
45VC Clamp 3A@8/20us Ipp ESD DIODE SOT-323
SOT-323ROHS3 CompliantActive
ESD DIODE 27VWM 45VC SOT-323
- Manufacturer
- Nexperia
- Manufacturer part #
- PESD1IVN27-UX
- Store part #
- C552465
- Package / case
- SOT-323
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,780 in stock
#C552465
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.97 | ₹64.85 |
| 50+ | ₹10.19 | ₹509.50 |
| 150+ | ₹8.80 | ₹1,320.00 |
| 500+ | ₹7.75 | ₹3,875.00 |
| 3,000+ | ₹6.92 | ₹20,760.00 |
| 6,000+ | ₹6.50 | ₹39,000.00 |
5 × ₹12.97
₹64.85
excl. GST
₹76.52 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PESD1IVN27-UX
₹64.85 for 5 + GST
Specifications
- Clamping Voltage
- 45V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 3A@8/20us
- Number of Channels
- 1
- Voltage - Breakdown
- 28V
- type
- ESD
- Reverse Leakage Current (Ir)
- 1nA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 27V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.022 g
Overview
ESD protection device in a small SOT323 (SC-70) Surface-Mounted Device (SMD) plastic package designed to protect automotive In-vehicle network bus lines from the damage caused by ElectroStatic discharge (ESD) and other transients.
Applications
- ESD protection for In - vehicle network lines in automotive environments
- CAN
- LIN
- FlexRay
- SENT
Key features
- Reverse stand - off voltage: VRWM = 27V
- Low clamping voltage: VCL = 36V at IPP = 3A
- ESD protection up to 30kV (IEC 61000 - 4 - 2)
- ESD protection up to 30kV (ISO 10605: C = 330 pF, R = 330Ω)
- ISO 7637 - 3: Pulse a: VS = - 150V / Pulse b: VS = +100V
- Ultra low leakage current: IRM < 1nA
- Qualified according to AEC - Q101 / Automotive grade
