NexperiaDatasheet (PDF)
PESD2CANFD27V-TR
44VC Clamp 2.5A@8/20us Ipp ESD DIODE SOT-23
SOT-23ROHS3 CompliantActive
ESD DIODE 27VWM 44VC SOT-23
- Manufacturer
- Nexperia
- Manufacturer part #
- PESD2CANFD27V-TR
- Store part #
- C552488
- Package / case
- SOT-23
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,716 in stock
#C552488
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹87.91 | ₹87.91 |
| 10+ | ₹71.16 | ₹711.60 |
| 30+ | ₹62.67 | ₹1,880.10 |
| 100+ | ₹54.19 | ₹5,419.00 |
| 500+ | ₹49.18 | ₹24,590.00 |
| 1,000+ | ₹46.57 | ₹46,570.00 |
1 × ₹87.91
₹87.91
excl. GST
₹103.73 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PESD2CANFD27V-TR
₹87.91 for 1 + GST
Specifications
- Clamping Voltage
- 44V
- Peak Pulse Current (Ipp)
- 2.5A@8/20us
- Voltage - Breakdown
- 38V
- Number of Channels
- 2
- type
- ESD
- Reverse Leakage Current (Ir)
- 50nA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 27V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.06 g
Overview
ESD protection device in a small SOT23 (TO-236AB) Surface-Mounted Device (SMD) plastic package designed to protect two automotive In-vehicle network bus lines from the damage caused by ElectroStatic discharge (ESD) and other transients.
Applications
- ESD protection for In-vehicle network lines in automotive environments
- CAN-FD
- CAN
- FlexRay
- SENT
Key features
- Reverse stand-off voltage: VRWM = 27 V
- Low clamping voltage: VCL = 33 V at IPP = 1 A
- ESD protection up to 20 kV (IEC 61000-4-2)
- Low capacitance: Cd = 6 pF
- ESD protection up to 20 kV (ISO 10605; C = 150 pF; R = 330 Ω)
- High temperature capability: Tj = 175 °C
- AEC-Q101 qualified
