NexperiaDatasheet (PDF)
PESD5V0S1BA,115
14VC Clamp 12A@8/20us Ipp ESD DIODE SOD-323
PopularSOD-323ROHS3 CompliantActive
ESD DIODE 5VWM 14VC SOD-323
- Manufacturer
- Nexperia
- Manufacturer part #
- PESD5V0S1BA,115
- Store part #
- C19224
- Package / case
- SOD-323
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
45,040 in stock
#C19224
Stock & price checked 19 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹11.39 | ₹56.95 |
| 50+ | ₹9.02 | ₹451.00 |
| 150+ | ₹7.81 | ₹1,171.50 |
| 500+ | ₹6.80 | ₹3,400.00 |
| 3,000+ | ₹6.46 | ₹19,380.00 |
| 6,000+ | ₹6.22 | ₹37,320.00 |
5 × ₹11.39
₹56.95
excl. GST
₹67.20 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PESD5V0S1BA,115
₹56.95 for 5 + GST
Specifications
- Clamping Voltage
- 14V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 12A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 130W@8/20us
- Number of Channels
- 1
- Voltage - Breakdown
- 9.5V
- type
- ESD
- Reverse Leakage Current (Ir)
- 5nA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.021 g
Overview
Bidirectional ElectroStatic Discharge (ESD) protection diode in very small SOD323 (SC-76) Surface-Mounted Device (SMD) plastic package designed to protect one signal line from the damage caused by ESD and other transients.
Applications
- Cellular handsets and accessories
- Portable electronics
- Computers and peripherals
- Communication systems
- Audio and video equipment
Key features
- Single-line bidirectional ESD protection
- Maximum peak pulse power: PPPM = 130 W
- Low clamp voltage: V(CL)R = 14 V
- Low leakage current: IRM = 5 nA
- ESD protection capability >30 kV
- Compliant with IEC 61000-4-2 Level 4 (ESD)
- Compliant with IEC 61000-4-5 (Surge); IPPM = 12 A
- Ultra-compact SMD plastic package
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | RLSD32A051C-ES#C19170905ElecSuper · SOD-323 | ElecSuper | SOD-323 | 4,850 | ₹2.55 · 4,850 in stock | View |
 | CDSOD323-T05SC#C22363661ElecSuper · SOD-323 | ElecSuper | SOD-323 | 5,000 | ₹2.74 · 5,000 in stock | View |
 | D5V0L1B2WS-7-ES#C22379588ElecSuper · SOD-323 | ElecSuper | SOD-323 | 2,550 | ₹2.43 · 2,550 in stock | View |
 | SLESD3Z5V0C-ES#C22379589ElecSuper · SOD-323 | ElecSuper | SOD-323 | 2,900 | ₹2.43 · 2,900 in stock | View |
 | MSESD5V0S1BA#C2836333MSKSEMI · SOD-323 | MSKSEMI | SOD-323 | 2,620 | ₹9.45 · 2,620 in stock | View |
