VBsemi ElecDatasheet (PDF)
PMPB07R3ENAX-VB
19W 30V 12A 20mΩ@10V 1 N-channel N-Channel SC-70-6L Single FETs, MOSFETs
SC-70-6LRoHSActive
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- PMPB07R3ENAX-VB
- Store part #
- C52148781
- Package / case
- SC-70-6L
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10 in stock
#C52148781
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹208.99 | ₹208.99 |
| 10+ | ₹174.38 | ₹1,743.80 |
| 30+ | ₹155.44 | ₹4,663.20 |
| 100+ | ₹133.89 | ₹13,389.00 |
| 500+ | ₹124.31 | ₹62,155.00 |
| 1,000+ | ₹120.17 | ₹1,20,170.00 |
1 × ₹208.99
₹208.99
excl. GST
₹246.61 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
PMPB07R3ENAX-VB
₹208.99 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 126pF
- Ciss-Input Capacitance
- 570pF
- Pd - Power Dissipation
- 19W
- Configuration
- Standalone
- Drain to Source Voltage
- 30V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 12A
- Reverse Transfer Capacitance (Crss)
- 52pF
- RDS(on)
- 20mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 5nC
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.274 g
Overview
Applications
- DC-DC converter and synchronous buck converter
- Soft turn-on reduces ringing voltage
- Fast turn-off enables high efficiency
- Reduced shoot-through probability
Key features
- Trench power MOSFET
- 100% gate resistance (Rg) tested
- RoHS compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | PMPB07R3ENX-VB#C52148771VBsemi Elec · SC-70-6L | VBsemi Elec | SC-70-6L | 10 | ₹208.99 · 10 in stock | View |
 | PMPB10ENZ-VB#C52148779VBsemi Elec · SC-70-6L | VBsemi Elec | SC-70-6L | 8 | ₹208.99 · 8 in stock | View |
 | PMPB20ENZ-VB#C52148780VBsemi Elec · SC-70-6L | VBsemi Elec | SC-70-6L | 4 | ₹208.99 · 4 in stock | View |
 | PMPB11EN,115-VB#C52191121VBsemi Elec · SC-70-6L | VBsemi Elec | SC-70-6L | 5 | ₹147.82 · 5 in stock | View |
 | BUK4D16-20X-VB#C52148646VBsemi Elec · SC-70-6L | VBsemi Elec | SC-70-6L | 10 | ₹208.99 · 10 in stock | View |
