RUNIC

RS2166XC5

1 4.5Ω 1.8V~5.5V SOT-353 Analog Switches, Multiplexers, Demultiplexers

SOT-353RoHSActive

Single Bilateral SPST Analog Switch

Manufacturer: RUNIC
Manufacturer part #: RS2166XC5
Store part #: C2762292
Package / case: SOT-353
Category: Analog Switches, Multiplexers, Demultiplexers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

18,820 in stock

#C2762292

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹25.89	₹129.45
50+	₹19.33	₹966.50
150+	₹16.52	₹2,478.00
500+	₹13.02	₹6,510.00

Quantity (min 5, multiples of 5)

5 × ₹25.89

₹129.45

excl. GST

₹152.75 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

RS2166XC5

₹129.45 for 5 + GST

Specifications

Features: Bidirectional analog channel
Operating Temperature: -40℃~+125℃
Number of Channels: 1
Ron: 4.5Ω
Voltage - Supply: 1.8V~5.5V
Con: 15pF

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.063 g

Overview

The RS2166 is a bidirectional 1-channel single-pole single-throw (SPST) analog switch, which is designed to operate from 1.8V to 5.5V. The RS2166 device can handle both analog and digital signals. It features bandwidth(300MHz) and low on-resistance (4.5Ω TYP). Each switch section has its own enable-input control (SEL). A high-level voltage applied to SEL turns on the associated switch section. Applications include signal gating, chopping, modulation or demodulation (modem), and signal multiplexing for analog-to-digital and digital-to-analog conversion systems.
