RUNIC

RS2251XS16

2.5V~5.5V 48Ω 1 SOIC-16 Analog Switches, Multiplexers, Demultiplexers

SOIC-16RoHSActive

CMOS Single 8-Channel Analog Multiplexer/Demultiplexer

Manufacturer: RUNIC
Manufacturer part #: RS2251XS16
Store part #: C237024
Package / case: SOIC-16
Category: Analog Switches, Multiplexers, Demultiplexers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,595 in stock

#C237024

Stock & price checked 27 h ago

Quantity	Unit price	Pack price
5+	₹29.71	₹148.55
50+	₹22.19	₹1,109.50
150+	₹18.96	₹2,844.00
500+	₹14.94	₹7,470.00

Quantity (min 5, multiples of 5)

5 × ₹29.71

₹148.55

excl. GST

₹175.29 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

RS2251XS16

₹148.55 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Features: Bidirectional analog channel;Glitch-free switching
Operating Temperature: -40℃~+125℃
Voltage - Supply: 2.5V~5.5V
Ron: 48Ω
Number of Channels: 1
Con: 16pF

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.24 g

Overview

The RS2251 is a CMOS analog IC configured as an 8-channel multiplexer. This CMOS device can operate from 2.5 V to 5.5 V. The RS2251 device are digitally-controlled analog switches. It has low on-resistance (48Ω TYP) and very low off-leakage current (1nA TYP). The RS2251 is available in Green SOIC-16, SSOP-16, TSSOP-16 and TQFN-3x3-16L packages. It operates over an ambient temperature range of -40°C to +125°C.
