RT6212BHGJ6F
500kHz Step-down type Adjustable 2A 800mV~15.48V TSOT-23-6L Voltage Regulators - DC DC Switching Regulators RoHS
TSOT-23-6LROHS3 CompliantActive
2A, 18V, 500kHz, ACOT™ Step-Down Converter
- Manufacturer
- RICHTEK
- Manufacturer part #
- RT6212BHGJ6F
- Store part #
- C411867
- Package / case
- TSOT-23-6L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,840 in stock
#C411867
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹51.73 | ₹258.65 |
| 50+ | ₹41.03 | ₹2,051.50 |
| 150+ | ₹36.44 | ₹5,466.00 |
| 500+ | ₹30.71 | ₹15,355.00 |
| 3,000+ | ₹27.53 | ₹82,590.00 |
| 6,000+ | ₹26.00 | ₹1,56,000.00 |
5 × ₹51.73
₹258.65
excl. GST
₹305.21 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
RT6212BHGJ6F
₹258.65 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃@(TA)
- Frequency - Switching
- 500kHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.5V~18V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 2A
- Output Voltage
- 800mV~15.48V
- Quiescent Current
- 500uA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.021 g
Overview
The RT6212A/B is a high-efficiency, monolithic synchronous step-down DC-DC converter that can deliver up to 2A output current from a 4.5V to 18V input supply. The RT6212A/B adopts ACOT architecture to allow the transient response to be improved and keep in constant frequency. Cycle-by-cycle current limit provides protection against shorted outputs and soft-start eliminates input current surge during start-up. Fault conditions also include output under-voltage protection, output over-current protection, and thermal shutdown.
Applications
- Set-Top Boxes
- Portable TVs
- Access Point Routers
- DSL Modems
- LCD TVs
Key features
- Integrated 163mΩ/86mΩ MOSFETs
- 4.5V to 18V Supply Voltage Range
- 500kHz Switching Frequency
- ACOT Control
- Feedback Reference Voltage 0.8V ±1.5%
- Feedback Reference Voltage 0.765V ±1.5%
- Internal Start-Up into Pre-Biased Outputs
- Compact Package: TSOT-23-6 Pin
- Input Under-Voltage Lockout
- Over-Current Protection and Hiccup
