SilergyDatasheet (PDF)
SA24403FCA
300kHz~2.2MHz Step-down type Adjustable 3.5A ESOP-8 Voltage Regulators - DC DC Switching Regulators
ESOP-8RoHSActive
High Efficiency Fast Response, 3.5A, 40V Input Synchronous Step Down Regulator
- Manufacturer
- Silergy
- Manufacturer part #
- SA24403FCA
- Store part #
- C7427423
- Package / case
- ESOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,412 in stock
#C7427423
Stock & price checked 36 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹119.90 | ₹119.90 |
| 10+ | ₹95.84 | ₹958.40 |
| 30+ | ₹83.92 | ₹2,517.60 |
| 100+ | ₹71.98 | ₹7,198.00 |
| 500+ | ₹64.84 | ₹32,420.00 |
| 1,000+ | ₹61.15 | ₹61,150.00 |
1 × ₹119.90
₹119.90
excl. GST
₹141.48 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SA24403FCA
₹119.90 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃@(TJ)
- Frequency - Switching
- 300kHz~2.2MHz
- Number of Outputs
- 1
- Function
- Step-down type
- Features
- Cycle-by-cycle current limiting;Hiccup current limiting;Light load efficient mode;Operating status indication
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.2V~40V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3.5A
- Quiescent Current
- 18uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.152 g
Overview
The SA24403 develops a high efficiency synchronous step-down DC/DC converter capable of delivering 3.5A load current. The SA24403 operates over a wide input voltage range from 4.2V to 40V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss. The SA24403 adopts peak current control scheme. The switching frequency is adjustable from 300kHz to 2.2MHz using an external resistor. The device also features ultra low quiescent operating to achieve high efficiency under light load. And the internal soft-start limits inrush current during power on.
Applications
- Automotive
- Industrial
- High-Voltage DC/DC Converters
Key features
- Low RDS(ON) for Internal Switches (Top/Bottom): 115/80mΩ
- 4.2 - 40V Input Voltage Range
- Internal Compensation
- Internal 1ms Soft-start Limits the Inrush Current
- Adjustable Switching Frequency Range: 300kHz to 2.2MHz
- 3.5A Output Current Capability
- ±2% 0.6V Reference Over -40°C ~ 125°C
- Cycle-by-cycle Peak Current Limitation
- Short Circuit Protection
- Thermal Shutdown and Auto Recovery
- RoHS Compliant and Halogen Free
- Compact Package: SO8E
- Automotive AEC - Q100 Grade 1 certified
