SG3524DR(UMW)

50mA SOP-16 Voltage Regulators - DC DC Switching Regulators RoHS

SOP-16ROHS CompliantActive

Pulse Width Modulation (PWM) circuits are used in switching power supplies.

Manufacturer: UMW
Manufacturer part #: SG3524DR(UMW)
Store part #: C7503196
Package / case: SOP-16
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,150 in stock

#C7503196

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹28.51	₹142.55
50+	₹22.25	₹1,112.50
150+	₹19.58	₹2,937.00
500+	₹16.23	₹8,115.00
2,500+	₹14.75	₹36,875.00
5,000+	₹13.85	₹69,250.00

Quantity (min 5, multiples of 5)

5 × ₹28.51

₹142.55

excl. GST

₹168.21 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

SG3524DR(UMW)

₹142.55 for 5 + GST

Specifications

Operating Temperature: 0℃~+70℃@(TA)
Number of Outputs: 2
Frequency - Switching: 100Hz~300kHz;40kHz
Features: Frequency synchronization;Overcurrent Protection
Topology: Push-Pull
Operating Voltage: 8V~40V
Output Current: 50mA
Quiescent Current: 10mA

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.331 g

Overview

UMW SG3524 is a pulse width modulation circuit designed for switching power supplies. It integrates a reference voltage source, error amplifier, oscillator, PWM comparator, pulse width control flip-flop, dual alternating outputs, current limiting circuit, and shutdown circuit. This device is applicable for switching power supply control of any polarity, transformer-coupled DC-DC switching power supplies, transformer boost and polarity inversion, and other power supply applications. The UMW SG3524 operates over a temperature range of 0°C to +70°C.
