SI4532CDY
30V 6A 1.1W Surface Mount SOIC-8
SOIC-8RoHSActive
MOSFET 30V 6A SOIC-8
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SI4532CDY
- Store part #
- C5123895
- Package / case
- SOIC-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,775 in stock
#C5123895
Stock & price checked 11 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹29.91 | ₹149.55 |
| 50+ | ₹23.91 | ₹1,195.50 |
| 150+ | ₹21.34 | ₹3,201.00 |
| 500+ | ₹18.13 | ₹9,065.00 |
| 3,000+ | ₹14.75 | ₹44,250.00 |
| 6,000+ | ₹13.89 | ₹83,340.00 |
5 × ₹29.91
₹149.55
excl. GST
₹176.47 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SI4532CDY
₹149.55 for 5 + GST
Specifications
- Output Capacitance(Coss)
- 59pF
- Ciss-Input Capacitance
- 846pF
- Pd - Power Dissipation
- 1.1W
- Drain to Source Voltage
- 30V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 6A
- Reverse Transfer Capacitance (Crss)
- 76pF
- RDS(on)
- 30mΩ@10V
- Number
- 1 N-Channel + 1 P-Channel
- Gate Charge(Qg)
- 7.8nC@15V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 1V
- Type
- N-Channel + P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.18 g
Overview
Applications
- Battery protection
- Load switch
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | IRF7309TRPBF#C5123894TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 5,670 | ₹21.75 · 5,670 in stock | View |
 | FDS8958A#C5123898TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 2,615 | ₹21.86 · 2,615 in stock | View |
 | AO4606#C5123896TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 5,695 | ₹25.00 · 5,695 in stock | View |
 | IRF7105TRPBF#C5123892TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 885 | ₹26.76 · 885 in stock | View |
 | SI4532DY#C5123913TECH PUBLIC · SOP-8 | TECH PUBLIC | SOP-8 | 3,105 | ₹19.46 · 3,105 in stock | View |
