SI4894BDY-T1-E3
30V 8.9A 1.4W 11mΩ@10V 1 N-channel SOIC-8 Single FETs, MOSFETs RoHS
SOIC-8ROHS3 CompliantActive
- Manufacturer
- VISHAY
- Manufacturer part #
- SI4894BDY-T1-E3
- Store part #
- C3279930
- Package / case
- SOIC-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C3279930
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹423.00 | ₹423.00 |
| 10+ | ₹416.98 | ₹4,169.80 |
| 30+ | ₹412.68 | ₹12,380.40 |
| 100+ | ₹408.61 | ₹40,861.00 |
1 × ₹423.00
₹423.00
excl. GST
₹499.14 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SI4894BDY-T1-E3
₹423.00 for 1 + GST
Specifications
- Drain to Source Voltage
- 30V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 8.9A
- Ciss-Input Capacitance
- 1.58nF
- Pd - Power Dissipation
- 1.4W
- RDS(on)
- 11mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 38nC@10V
- Gate Threshold Voltage (Vgs(th))
- 3V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.413 g
Overview
These N-channel enhancement-mode power MOSFETs are manufactured using a proprietary high cell density DMOS technology. This ultra-high density process is specifically designed to minimize on-resistance and deliver superior switching performance. These devices are particularly suited for low-voltage applications such as DC/DC conversion, disk drive motor control, and other battery-powered circuits requiring fast switching, low in-line power dissipation, and ruggedness against transients.
Applications
- DC/DC conversion - Disk drive motor control - Other battery-powered circuits
Key features
- Halogen-free product compliant with IEC 61249-2-21
- TrenchFET power MOSFET
- 100% gate resistance (Rg) tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | CJQ14SN06#C504130JSCJ · SOP-8 | JSCJ | SOP-8 | 7,015 | ₹44.53 · 7,015 in stock | View |
 | SI4420BDY-T1-E3#C7010733VISHAY · SOIC-8 | VISHAY | SOIC-8 | 251 | ₹146.68 · 251 in stock | View |
 | DMT68M8LSS-13#C6832285DIODES · SO-8 | DIODES | SO-8 | 611 | ₹58.46 · 611 in stock | View |
| DMT6005LSS-13#C5245424DIODES · SO-8 | DIODES | SO-8 | 3 | ₹209.76 · 3 in stock | View | |
 | NTMS4816NR2G#C179627onsemi · SO-8 | onsemi | SO-8 | 17 | ₹122.59 · 17 in stock | View |
