HXY MOSFETDatasheet (PDF)
SI7164DP-T1-GE3-HXY
108W 60V 80A 6mΩ@10V 1 N-channel N-Channel DFN-8L(5x6) Single FETs, MOSFETs
DFN-8L(5x6)RoHSActive
- Manufacturer
- HXY MOSFET
- Manufacturer part #
- SI7164DP-T1-GE3-HXY
- Store part #
- C53262871
- Package / case
- DFN-8L(5x6)
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
83 in stock
#C53262871
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹157.86 | ₹157.86 |
| 10+ | ₹132.95 | ₹1,329.50 |
| 30+ | ₹119.20 | ₹3,576.00 |
| 100+ | ₹103.74 | ₹10,374.00 |
| 500+ | ₹96.87 | ₹48,435.00 |
| 1,000+ | ₹93.85 | ₹93,850.00 |
1 × ₹157.86
₹157.86
excl. GST
₹186.27 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SI7164DP-T1-GE3-HXY
₹157.86 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 286pF
- Ciss-Input Capacitance
- 4.136nF
- Pd - Power Dissipation
- 108W
- Drain to Source Voltage
- 60V
- Configuration
- Standalone
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 80A
- Reverse Transfer Capacitance (Crss)
- 257pF
- RDS(on)
- 6mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 90nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.136 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | NVMFD5C668NLWFT1G-HXY#C51949326HXY MOSFET · DFN-8L(5x6) | HXY MOSFET | DFN-8L(5x6) | 97 | ₹166.23 · 97 in stock | View |
 | SIR664DP-T1-GE3-HXY#C53262841HXY MOSFET · DFN-8L(5x6) | HXY MOSFET | DFN-8L(5x6) | 61 | ₹131.88 · 61 in stock | View |
 | NTMFS5C670NLT3G-HXY#C53262844HXY MOSFET · DFN-8L(5x6) | HXY MOSFET | DFN-8L(5x6) | 385 | ₹54.56 · 385 in stock | View |
 | NVMFS5C670NLWFAFT1G-HXY#C53262850HXY MOSFET · DFN-8L(5x6) | HXY MOSFET | DFN-8L(5x6) | 97 | ₹185.78 · 97 in stock | View |
 | NVMFS5C670NLT1G-HXY#C53262859HXY MOSFET · DFN-8L(5x6) | HXY MOSFET | DFN-8L(5x6) | 99 | ₹171.61 · 99 in stock | View |
