SIR180ADP-T1-RE3
60V 35A 83.3W 2.8mΩ@7.5V 1 N-channel N-Channel PowerPAK-SO-8 Single FETs, MOSFETs RoHS
PowerPAK-SO-8ROHS3 CompliantActive
N-Channel, Current: 1379A, Voltage: 60V
- Manufacturer
- VISHAY
- Manufacturer part #
- SIR180ADP-T1-RE3
- Store part #
- C3289471
- Package / case
- PowerPAK-SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
20 in stock
#C3289471
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹334.55 | ₹334.55 |
| 10+ | ₹329.14 | ₹3,291.40 |
| 30+ | ₹325.66 | ₹9,769.80 |
| 100+ | ₹321.98 | ₹32,198.00 |
1 × ₹334.55
₹334.55
excl. GST
₹394.77 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SIR180ADP-T1-RE3
₹334.55 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 35A
- Ciss-Input Capacitance
- 3.28nF
- Pd - Power Dissipation
- 83.3W
- Reverse Transfer Capacitance (Crss)
- 46.2pF
- RDS(on)
- 2.8mΩ@7.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 70nC@10V
- Gate Threshold Voltage (Vgs(th))
- 3.6V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.82 g
Overview
Applications
- Synchronous rectification
- Primary-side switching
- DC/DC converters
- Motor drive switching
Key features
- 4th Generation TrenchFET Power MOSFET
- Ultra-low R<sub>DS(on)</sub>-Q<sub>g</sub> FOM
- Optimized for lowest R<sub>DS(on)</sub>-C<sub>oss</sub> FOM
- 100% tested for R<sub>θ</sub> and UIS
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | BSC028N06NS#C148250Infineon · TDSON-8(5x6) | Infineon | TDSON-8(5x6) | 19,797 | ₹165.47 · 19,797 in stock | View |
 | BSC028N06NSSC#C534317Infineon · TDSON-8(5.9x5.2) | Infineon | TDSON-8(5.9x5.2) | 72 | ₹551.78 · 72 in stock | View |
 | MGC031N06N#C49242753Megain · PDFN5x6-8 | Megain | PDFN5x6-8 | 3,320 | ₹31.94 · 3,320 in stock | View |
 | HSBA6048A#C45385121HUASHUO · PRPAK5x6-8L | HUASHUO | PRPAK5x6-8L | 122 | ₹84.63 · 122 in stock | View |
 | HYG053N10NS1C2#C2986239HUAYI · PDFN5x6-8L | HUAYI | PDFN5x6-8L | 2 | ₹73.51 · 2 in stock | View |
