MDD(Microdiode Semiconductor)
2N7002KN-Channel 60V 300mA 300mW Surface Mount SOT-23
From
₹2.32
25,99,250 in stock
VISHAYDatasheet (PDF)
SIR846BDP-T1-RE3
100V 65.8A 5W 9mΩ@7.5V 1 N-channel N-Channel PowerPAK-SO-8 Single FETs, MOSFETs RoHS
PowerPAK-SO-8ROHS3 CompliantActive
N-Channel, Current:65.8A, Voltage:100V
- Manufacturer
- VISHAY
- Manufacturer part #
- SIR846BDP-T1-RE3
- Store part #
- C3289469
- Package / case
- PowerPAK-SO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
18 in stock
#C3289469
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹160.37 | ₹160.37 |
| 10+ | ₹156.68 | ₹1,566.80 |
| 30+ | ₹154.06 | ₹4,621.80 |
| 100+ | ₹151.68 | ₹15,168.00 |
1 × ₹160.37
₹160.37
excl. GST
₹189.24 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SIR846BDP-T1-RE3
₹160.37 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 100V
- Current - Continuous Drain(Id)
- 65.8A
- Ciss-Input Capacitance
- 2.44nF
- Pd - Power Dissipation
- 5W
- Reverse Transfer Capacitance (Crss)
- 34.5pF
- RDS(on)
- 9mΩ@7.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 40nC@10V
- Gate Threshold Voltage (Vgs(th))
- 4V
- Type
- N-Channel
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.222 g
Overview
Applications
- Synchronous rectification
- Primary-side switching
- DC/DC converter
- Power supply
- Motor drive control
Key features
- TrenchFET 4th Generation Power MOSFET
- Ultra-low RDS × Qg figure of merit (FOM)
- Optimized for lowest RDS × Qoss FOM
- 100% Rg and UIS tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SIR106ADP-T1-RE3#C3279521VISHAY · PowerPAKSO-8 | VISHAY | PowerPAKSO-8 | 166 | ₹294.01 · 166 in stock | View |
 | AGM15T13A#C5297525AGMSEMI · PDFN5x6-8L | AGMSEMI | PDFN5x6-8L | 810 | ₹158.06 · 810 in stock | View |
| DMTH12H007SPS-13#C6934930DIODES · PowerDI5060-8 | DIODES | PowerDI5060-8 | 18 | ₹247.61 · 18 in stock | View | |
 | HSBA0715#C2987716HUASHUO · PRPAK5x6-8L | HUASHUO | PRPAK5x6-8L | 482 | ₹256.17 · 482 in stock | View |
 | BSC070N10NS5#C534364Infineon · TDSON-8(5x6) | Infineon | TDSON-8(5x6) | 27,174 | ₹78.53 · 27,174 in stock | View |
