SIRA84BDP-T1-GE3
N-Channel 30V 70A 3.7W Surface Mount PowerPAKSO-8
PowerPAKSO-8ROHS3 CompliantActive
MOSFET N-CH 30V 70A PowerPAKSO-8
- Manufacturer
- VISHAY
- Manufacturer part #
- SIRA84BDP-T1-GE3
- Store part #
- C6816940
- Package / case
- PowerPAKSO-8
- Category
- Single FETs, MOSFETs
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
9 in stock
#C6816940
Stock & price checked 4 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹67.09 | ₹67.09 |
| 10+ | ₹65.48 | ₹654.80 |
| 30+ | ₹64.46 | ₹1,933.80 |
| 100+ | ₹63.24 | ₹6,324.00 |
1 × ₹67.09
₹67.09
excl. GST
₹79.17 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SIRA84BDP-T1-GE3
₹67.09 for 1 + GST
Specifications
- Drain to Source Voltage
- 30V
- Operating Temperature
- -55℃~+150℃
- Current - Continuous Drain(Id)
- 70A
- Ciss-Input Capacitance
- 1.05nF
- Pd - Power Dissipation
- 3.7W
- Reverse Transfer Capacitance (Crss)
- 80pF
- RDS(on)
- 4.6mΩ@10V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 10.6nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.4V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.13 g
Overview
Applications
- High power density DC/DC
- Synchronous rectification
- Voltage Regulation Module (VRM) and embedded DC/DC
Key features
- TrenchFET 4th generation power MOSFET
- 100% Rg and UIS tested
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | DON80N03#C42386231DOINGTER · DFN5x6-8 | DOINGTER | DFN5x6-8 | 1,740 | ₹15.82 · 1,740 in stock | View |
 | ASDM40N80Q-R#C2972880ASDsemi · DFN5x6-8 | ASDsemi | DFN5x6-8 | 4,525 | ₹31.12 · 4,525 in stock | View |
 | TW120N03EF#C42417395TWGMC · PDFN5x6-8 | TWGMC | PDFN5x6-8 | 1,245 | ₹22.94 · 1,245 in stock | View |
 | TDM3452#C380223Techcode · DFN-8(5x6) | Techcode | DFN-8(5x6) | 349 | ₹74.15 · 349 in stock | View |
 | CSD17311Q5-VB#C47993910VBsemi Elec · DFN5x6-8 | VBsemi Elec | DFN5x6-8 | 10 | ₹145.93 · 10 in stock | View |
