STDatasheet (PDF)
SM4T10AY
19.5VC Clamp 124A@8/20us Ipp TVS DIODE SMA(DO-214AC)
SMA(DO-214AC)ROHS3 CompliantActive
TVS DIODE 8.5VWM 19.5VC SMA(DO-214AC)
- Manufacturer
- ST
- Manufacturer part #
- SM4T10AY
- Store part #
- C1974392
- Package / case
- SMA(DO-214AC)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
48 in stock
#C1974392
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹131.81 | ₹131.81 |
| 10+ | ₹107.98 | ₹1,079.80 |
| 30+ | ₹94.90 | ₹2,847.00 |
| 100+ | ₹80.08 | ₹8,008.00 |
| 500+ | ₹73.43 | ₹36,715.00 |
| 1,000+ | ₹70.42 | ₹70,420.00 |
1 × ₹131.81
₹131.81
excl. GST
₹155.54 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
SM4T10AY
₹131.81 for 1 + GST
Specifications
- Clamping Voltage
- 19.5V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 124A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 2.3kW@8/20us
- Number of Channels
- 1
- Voltage - Breakdown
- 9.9V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 20uA
- Reverse Stand-Off Voltage (Vrwm)
- 8.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.13 g
