VISHAYDatasheet (PDF)
SMBJ6.0CA-E3/52
10.3VC Clamp 58.3A Ipp TVS DIODE SMB(DO-214AA)
SMB(DO-214AA)ROHS3 CompliantActive
TVS DIODE 6VWM 10.3VC SMB(DO-214AA)
- Manufacturer
- VISHAY
- Manufacturer part #
- SMBJ6.0CA-E3/52
- Store part #
- C83659
- Package / case
- SMB(DO-214AA)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,460 in stock
#C83659
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹26.58 | ₹132.90 |
| 50+ | ₹20.94 | ₹1,047.00 |
| 150+ | ₹18.52 | ₹2,778.00 |
| 750+ | ₹15.51 | ₹11,632.50 |
| 2,250+ | ₹14.16 | ₹31,860.00 |
| 5,250+ | ₹13.36 | ₹70,140.00 |
5 × ₹26.58
₹132.90
excl. GST
₹156.82 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 750 per reel
SMBJ6.0CA-E3/52
₹132.90 for 5 + GST
Specifications
- Clamping Voltage
- 10.3V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 58.3A
- Peak Pulse Power Dissipation (Ppp)
- 600W
- Number of Channels
- 1
- Voltage - Breakdown
- 6.67V
- type
- TVS
- Reverse Leakage Current (Ir)
- 800uA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 6V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 750 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.217 g
