TECH PUBLICDatasheet (PDF)
SMC12
10VC Clamp 8A@8/20us Ipp ESD DIODE SOT23-5
SOT23-5RoHSActive
ESD DIODE 12VWM 10VC SOT23-5
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SMC12
- Store part #
- C5370967
- Package / case
- SOT23-5
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,020 in stock
#C5370967
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.01 | ₹70.10 |
| 100+ | ₹5.52 | ₹552.00 |
| 300+ | ₹4.76 | ₹1,428.00 |
| 3,000+ | ₹4.19 | ₹12,570.00 |
| 6,000+ | ₹3.74 | ₹22,440.00 |
| 9,000+ | ₹3.52 | ₹31,680.00 |
10 × ₹7.01
₹70.10
excl. GST
₹82.72 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMC12
₹70.10 for 10 + GST
Specifications
- Clamping Voltage
- 10V
- Operating Temperature
- -55℃~+125℃
- Peak Pulse Current (Ipp)
- 8A@8/20us
- Peak Pulse Power Dissipation (Ppp)
- 80W@8/20us
- Number of Channels
- 2
- Voltage - Breakdown
- 13.6V
- type
- TVS
- Polarity
- Bidirectional
- Reverse Leakage Current (Ir)
- 50nA
- Reverse Stand-Off Voltage (Vrwm)
- 12V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.032 g
Overview
Applications
- Cellular Handsets and Accessories
- Notebooks and Handhelds
- Portable Instrumentation
- Set Top Box
Key features
- 80w peak pulse power(8/20μs)
- Ultra low leakage: nA level
- Operating voltage: 12V
- Low clamping voltage
- Complies with following standards:
- IEC61000 - 4 - 2(ESD) immunity test: Air discharge: ±30kV, Contact discharge: ±30kV
- IEC61000 - 4 - 4(EFT) 40A(5/50ns)
- IEC61000 - 4 - 5 (Lightning) 8A (8/20μs)
- RoHS Compliant
