VISHAYDatasheet (PDF)
SMCJ110CA-E3/57T
177VC Clamp 8.5A Ipp TVS DIODE SMC(DO-214AB)
SMC(DO-214AB)ROHS3 CompliantActive
TVS DIODE 110VWM 177VC SMC(DO-214AB)
- Manufacturer
- VISHAY
- Manufacturer part #
- SMCJ110CA-E3/57T
- Store part #
- C3715422
- Package / case
- SMC(DO-214AB)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
17 in stock
#C3715422
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹57.54 | ₹57.54 |
| 10+ | ₹45.75 | ₹457.50 |
| 30+ | ₹40.67 | ₹1,220.10 |
| 100+ | ₹34.57 | ₹3,457.00 |
| 500+ | ₹31.73 | ₹15,865.00 |
| 850+ | ₹29.89 | ₹25,406.50 |
1 × ₹57.54
₹57.54
excl. GST
₹67.90 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 850 per reel
SMCJ110CA-E3/57T
₹57.54 for 1 + GST
Specifications
- Clamping Voltage
- 177V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 8.5A
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW
- Number of Channels
- 1
- Voltage - Breakdown
- 122V
- type
- TVS
- Reverse Leakage Current (Ir)
- 1uA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 110V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 850 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.389 g
Overview
Applications
- Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, automotive, and telecommunication.
Key features
- Low profile package
- Ideal for automated placement
- Glass passivated chip junction
- Available in unidirectional and bidirectional
- Excellent clamping capability
- Very fast response time
- Low incremental surge resistance
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
- Automotive ordering code: base P/NHE3 or P/NHM3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMCJ110CA#C2990156Liown · SMC(DO-214AB) | Liown | SMC(DO-214AB) | 2,745 | ₹15.80 · 2,745 in stock | View |
 | SMCJ110CA#C310001Brightking · SMC(DO-214AB) | Brightking | SMC(DO-214AB) | 1,890 | ₹21.79 · 1,890 in stock | View |
| 1.5SMC130CA#C1975387Littelfuse · DO-214AB(SMCJ) | Littelfuse | DO-214AB(SMCJ) | 114 | ₹87.91 · 114 in stock | View | |
 | SMCJ110CA#C4154690TWGMC · DO-214AB(SMC) | TWGMC | DO-214AB(SMC) | 2,525 | ₹16.66 · 2,525 in stock | View |
 | SMCJ110CA#C438229Jingdao Microelectronics · SMC | Jingdao Microelectronics | SMC | 2,860 | ₹16.92 · 2,860 in stock | View |
