R+ODatasheet (PDF)
SMCJ24CA
38.9VC Clamp 38.6A Ipp TVS DIODE SMC(DO-214AB)
SMC(DO-214AB)ROHS CompliantActive
TVS DIODE 24VWM 38.9VC SMC(DO-214AB)
- Manufacturer
- R+O
- Manufacturer part #
- SMCJ24CA
- Store part #
- C41411747
- Package / case
- SMC(DO-214AB)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
8,725 in stock
#C41411747
Stock & price checked 29 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹18.67 | ₹93.35 |
| 50+ | ₹15.21 | ₹760.50 |
| 150+ | ₹13.49 | ₹2,023.50 |
| 500+ | ₹12.20 | ₹6,100.00 |
| 3,000+ | ₹9.37 | ₹28,110.00 |
| 6,000+ | ₹8.85 | ₹53,100.00 |
5 × ₹18.67
₹93.35
excl. GST
₹110.15 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMCJ24CA
₹93.35 for 5 + GST
Specifications
- Clamping Voltage
- 38.9V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 38.6A
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 29.5V
- type
- TVS
- Reverse Leakage Current (Ir)
- 1uA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 24V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2a
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.376 g
