VISHAYDatasheet (PDF)
SMCJ33A-E3/57T
53.3VC Clamp 28.1A Ipp TVS DIODE SMC(DO-214AB)
SMC(DO-214AB)ROHS3 CompliantActive
TVS DIODE 33VWM 53.3VC SMC(DO-214AB)
- Manufacturer
- VISHAY
- Manufacturer part #
- SMCJ33A-E3/57T
- Store part #
- C435941
- Package / case
- SMC(DO-214AB)
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
40 in stock
#C435941
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹52.42 | ₹262.10 |
| 50+ | ₹43.57 | ₹2,178.50 |
| 150+ | ₹39.77 | ₹5,965.50 |
| 850+ | ₹32.27 | ₹27,429.50 |
| 2,550+ | ₹30.16 | ₹76,908.00 |
| 5,100+ | ₹28.89 | ₹1,47,339.00 |
5 × ₹52.42
₹262.10
excl. GST
₹309.28 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 850 per reel
SMCJ33A-E3/57T
₹262.10 for 5 + GST
Specifications
- Clamping Voltage
- 53.3V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 28.1A
- Peak Pulse Power Dissipation (Ppp)
- 1.5kW
- Number of Channels
- 1
- Voltage - Breakdown
- 36.7V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 1uA
- Reverse Stand-Off Voltage (Vrwm)
- 33V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 850 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.36 g
Overview
Applications
- Use in sensitive electronics protection against voltage transients induced by inductive load switching and lighting on ICs, MOSFET, signal lines of sensor units for consumer, computer, industrial, automotive, and telecommunication.
Key features
- Low profile package
- Ideal for automated placement
- Glass passivated chip junction
- Available in uni-directional and bi-directional
- Excellent clamping capability
- Very fast response time
- Low incremental surge resistance
- Meets MSL level 1, per J-STD-020, LF maximum peak of 260℃
- AEC-Q101 qualified available
- Material categorization: for definitions of compliance please see doc?99912
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SMCJ33A-E3/9AT#C1975262VISHAY · SMC(DO-214AB) | VISHAY | SMC(DO-214AB) | 739 | ₹74.31 · 739 in stock | View |
| SMCJ33A#C3719905BOURNS · DO-214AB(SMC) | BOURNS | DO-214AB(SMC) | 24 | ₹93.07 · 24 in stock | View | |
 | SMCJ33A#C434871RUILON · DO-214AB(SMC) | RUILON | DO-214AB(SMC) | 2,255 | ₹21.55 · 2,255 in stock | View |
 | 1.5SMCJ33A-AU_R1_000A1#C5177361PANJIT · DO-214AB(SMC) | PANJIT | DO-214AB(SMC) | 330 | ₹53.71 · 330 in stock | View |
 | SMCJ33A#C5861033JUXING · SMC | JUXING | SMC | 1,485 | ₹15.82 · 1,485 in stock | View |
