LittelfuseDatasheet (PDF)
SMDJ60CA
96.8VC Clamp 31A Ipp TVS DIODE DO-214AB
DO-214ABROHS3 CompliantActive
TVS DIODE 60VWM 96.8VC DO-214AB
- Manufacturer
- Littelfuse
- Manufacturer part #
- SMDJ60CA
- Store part #
- C2649874
- Package / case
- DO-214AB
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
480 in stock
#C2649874
Stock & price checked 18 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹85.17 | ₹85.17 |
| 10+ | ₹72.13 | ₹721.30 |
| 30+ | ₹66.49 | ₹1,994.70 |
| 100+ | ₹59.32 | ₹5,932.00 |
| 500+ | ₹56.28 | ₹28,140.00 |
| 1,000+ | ₹54.32 | ₹54,320.00 |
1 × ₹85.17
₹85.17
excl. GST
₹100.50 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMDJ60CA
₹85.17 for 1 + GST
Specifications
- Clamping Voltage
- 96.8V
- Operating Temperature
- -65℃~+150℃
- Peak Pulse Current (Ipp)
- 31A
- Peak Pulse Power Dissipation (Ppp)
- 3kW@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 66.7V
- type
- TVS
- Reverse Leakage Current (Ir)
- 2uA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 60V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.606 g
