TECH PUBLICDatasheet (PDF)
SMF22CA
35.5VC Clamp 5.6A Ipp TVS DIODE SOD-123FL
SOD-123FLRoHSActive
TVS DIODE 22VWM 35.5VC SOD-123FL
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SMF22CA
- Store part #
- C42440483
- Package / case
- SOD-123FL
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
760 in stock
#C42440483
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹1.79 | ₹35.80 |
| 200+ | ₹1.75 | ₹350.00 |
| 600+ | ₹1.72 | ₹1,032.00 |
| 3,000+ | ₹1.69 | ₹5,070.00 |
20 × ₹1.79
₹35.80
excl. GST
₹42.24 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SMF22CA
₹35.80 for 20 + GST
Specifications
- Clamping Voltage
- 35.5V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 5.6A
- Peak Pulse Power Dissipation (Ppp)
- 200W@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 26.9V
- type
- TVS
- Reverse Leakage Current (Ir)
- 1uA
- Polarity
- Bidirectional
- Reverse Stand-Off Voltage (Vrwm)
- 22V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.042 g
Overview
Applications
- Personal digital assistants (PDA)
- Cellular handsets & Accessories
- Handhelds and notebooks
- Portable instrumentation
Key features
- Peak power disspation: 200W@10×1000 us Pluse
- Low incremental surge resistance
- Excellent clamping capability
- Fast response time
- Low leakage current
- Halogen free and RoHS compliant
