SN74LVC1G66DCKR-JSM JSMSEMI
JSMSEMI

SN74LVC1G66DCKR-JSM

195Ω 1 1.65V~5.5V SOT-353 Analog Switches, Multiplexers, Demultiplexers RoHS

SOT-353ROHS CompliantActive
Manufacturer
JSMSEMI
Manufacturer part #
SN74LVC1G66DCKR-JSM
Store part #
C53114328
Package / case
SOT-353
Category
Analog Switches, Multiplexers, Demultiplexers
Packaging
Tape & Reel (TR)
Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,965 in stock

#C53114328

Stock & price checked 5 days ago

QuantityUnit pricePack price
5+₹12.28₹61.40
50+₹9.78₹489.00
150+₹8.53₹1,279.50
500+₹7.59₹3,795.00
3,000+₹6.84₹20,520.00
6,000+₹6.47₹38,820.00

5 × ₹12.28

₹61.40

excl. GST

₹72.45 incl. 18% GST

Need volume or a scheduled delivery? Request a quote
  • Dispatch in 7–10 working days
  • GST invoice with every order
  • Standard pack: 3,000 per reel

SN74LVC1G66DCKR-JSM

₹61.40 for 5 + GST

Specifications

Operating Temperature
-40℃~+125℃
Features
Bidirectional analog channel
Ron
195Ω
Number of Channels
1
Voltage - Supply
1.65V~5.5V
Propagation Delay
600ps
Con
11pF

Packaging & compliance

RoHS
ROHS Compliant
Lifecycle
Active
Packaging
Tape & Reel (TR)
Standard pack
3,000 / Reel
Sold per
Piece
Minimum order
5 (multiples of 5)
Unit weight
0.034 g

Overview

SN74LVC1G66DCKR-JSM provides a single-pole single-throw analog switch function. It features two input/output terminals (Y and Z) and an active-high enable input pin (E). When E is low, the analog switch turns off.

Key features

  • Wide supply voltage range, 1.65 V to 5.5 V
  • Ultra-low on-resistance
  • 32 mA switching current capability
  • CMOS low power consumption
  • Specified operating temperature range: -40℃ to +125℃
  • Package: SOT-353
