TECH PUBLICDatasheet (PDF)
SRDA3.3-4DR2G
nan
SOP-8RoHSActive
3.3VWM 15VC SOP-8
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SRDA3.3-4DR2G
- Store part #
- C19829486
- Package / case
- SOP-8
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
984 in stock
#C19829486
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹66.94 | ₹66.94 |
| 10+ | ₹59.44 | ₹594.40 |
| 30+ | ₹55.69 | ₹1,670.70 |
| 100+ | ₹51.93 | ₹5,193.00 |
| 500+ | ₹49.64 | ₹24,820.00 |
| 1,000+ | ₹48.40 | ₹48,400.00 |
1 × ₹66.94
₹66.94
excl. GST
₹78.99 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
SRDA3.3-4DR2G
₹66.94 for 1 + GST
Specifications
- Clamping Voltage
- 15V
- Peak Pulse Power Dissipation (Ppp)
- 500W@8/20us
- Voltage - Breakdown
- 4.5V
- Number of Channels
- Four channels
- Reverse Leakage Current (Ir)
- 2uA
- Reverse Stand-Off Voltage (Vrwm)
- 3.3V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.79 g
Overview
Applications
- T1/E1 Line Cards
- T3/E3 and DS3 Interfaces
- STS-1 Interfaces
- 10/100/1000 BaseT Ethernet
- Set Top Box
- ISDN Interfaces
- Low Voltage Interfaces
Key features
- Protects four I/O lines
- Low capacitance (7pF) Max
- Low operating voltage: 3.3V
- Low clamping voltage
- Protects two lines in common and differential mode
- Complies with following standards:
- IEC 61000-4-2 (ESD) immunity test Air discharge: ±30kV Contact discharge: ±30kV
- IEC61000-4-5 (Lightning) 25A (8/20 μs)
- RoHS Comnliant
