STM32L011F4U6TR

ARM Cortex-M0+ 32 Bit 32MHz UFQFPN-20(3x3) Microcontrollers RoHS

UFQFPN-20(3x3)ROHS3 CompliantActive

Access line ultra-low-power 32-bit MCU Arm-based

Manufacturer: ST
Manufacturer part #: STM32L011F4U6TR
Store part #: C329283
Package / case: UFQFPN-20(3x3)
Category: Microcontrollers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

12,143 in stock

#C329283

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹221.76	₹221.76
10+	₹189.19	₹1,891.90
30+	₹171.37	₹5,141.10
100+	₹139.01	₹13,901.00
500+	₹130.10	₹65,050.00
1,000+	₹125.98	₹1,25,980.00

Quantity (min 1)

1 × ₹221.76

₹221.76

excl. GST

₹261.68 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

STM32L011F4U6TR

₹221.76 for 1 + GST

Specifications

ADC (Bit): 12bit
Number of I/O: 16
Operating Temperature: -40℃~+85℃
Program Memory Type: FLASH
Voltage - Supply: 1.65V~3.6V
EEPROM: 512Byte
Program Storage Size: 16KB
CPU Core: ARM Cortex-M0+
Core Size: 32 Bit
CPU Maximum Speed: 32MHz
Oscillator Type: Built-in

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: 3A991A2
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.128 g

Overview

Access line ultra-low-power 32-bit MCU Arm-based Cortex-MO+, up to 16KB Flash, 2KB SRAM, 512B EEPROM, ADC

Key features

Ultra-low-power platform
1.65 V to 3.6 V power supply
-40 to 125 ℃ temperature range
0.23 μA Standby mode (2 wakeup pins)
0.29 μA Stop mode (16 wakeup lines)
0.54 μA Stop mode + RTC + 2 KB RAM retention
Down to 76 μA/MHz in Run mode
5 μs wakeup time (from Flash memory)
41 μA 12-bit ADC conversion at 10 ksps
Core: Arm 32-bit Cortex-M0+
From 32 kHz to 32 MHz max.
0.95 DMIPS/MHz
Reset and supply management
Ultra-safe, low-power BOR (brownout reset) with 5 selectable thresholds
Ultralow power POR/PDR
Programmable voltage detector (PVD)
Clock sources
0 to 32 MHz external clock
32 kHz oscillator for RTC with calibration
High speed internal 16 MHz factory-trimmed RC (+/-1%)
Internal low-power 37 kHz RC
Internal multispeed low-power 65 kHz to 4.2 MHz RC PLL for CPU clock
Pre-programmed bootloader
USART, SPI supported
Development support
Serial wire debug supported
Up to 28 fast I/Os (23 I/Os 5V tolerant)
Memories
Up to 16 KB Flash memory with ECC
2 KB RAM
512 B of data EEPROM with ECC
20-byte backup register
Sector protection against R/W operation
Rich Analog peripherals
12-bit ADC 1.14 Msps up to 10 channels (down to 1.65 V)
2x ultra-low-power comparators (window mode and wake up capability, down to 1.65 V)
5-channel DMA controller, supporting ADC, SPI, I2C, USART, Timers
4x peripherals communication interface
1x USART (ISO 7816, IrDA), 1x UART (low power)
1x SPI 16 Mbits/s
1x I2C (SMBus/PMBus)
7x timers: 1x 16-bit with up to 4 channels, 1x 16-bit with up to 2 channels, 1x 16-bit ultra-low-power timer, 1x SysTick, 1x RTC and 2x watchdogs (independent/window)
CRC calculation unit, 96-bit unique ID
All packages are ECOPACK2
