SilergyDatasheet (PDF)
SY7072ABC
Boost Switching Regulator IC Adjustable 1.8V~5.5V 1 Output 2A SOT-23-6
SOT-23-6ROHS CompliantActive
High-efficiency 2A valley current synchronous boost converter
- Manufacturer
- Silergy
- Manufacturer part #
- SY7072ABC
- Store part #
- C22809053
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,441 in stock
#C22809053
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹57.15 | ₹57.15 |
| 10+ | ₹45.64 | ₹456.40 |
| 30+ | ₹40.64 | ₹1,219.20 |
| 100+ | ₹34.35 | ₹3,435.00 |
| 500+ | ₹31.51 | ₹15,755.00 |
| 1,000+ | ₹29.99 | ₹29,990.00 |
1 × ₹57.15
₹57.15
excl. GST
₹67.44 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SY7072ABC
₹57.15 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Function
- Boost
- Number of Outputs
- 1
- Frequency - Switching
- 1MHz
- Features
- Load disconnect;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Boost
- Operating Voltage
- 1.8V~5.5V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 2A
- Output Voltage
- 1.8V~5.5V
- Quiescent Current
- 5uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.03 g
Overview
SY7072 is a high-efficiency synchronous boost converter designed for single-cell Li-ion or Li-polymer batteries, or two-to-three-cell alkaline, NiCd, or NiMH battery-powered applications. Its minimum input voltage can be as low as 1.8V. The device uses an NMOS as the main switch and a PMOS as the synchronous switch. In shutdown mode, the SY7072 can disconnect the output from the input. When the input voltage exceeds the regulated output voltage, the SY7072 automatically enters bypass mode.
Applications
- MP3 players
- PDAs
- Other portable devices
Key features
- Minimum input voltage 1.8V
- Adjustable output voltage range 1.8V to 5.5V
- Minimum 2A valley current limit
- Typical quiescent current 5µA
- Load disconnect during shutdown
- Low on-resistance (main switch/sync switch) at 3.3V output: 100/170mΩ
- Output overvoltage protection
- Automatic bypass mode when ΔVIN ≥ VOUT
- RoHS compliant and halogen-free
- Compact SOT23-6 package
