SilergyDatasheet (PDF)
SY8303AAIC
500kHz~2.5MHz Step-down type Adjustable 3A TSOT-23-8 Voltage Regulators - DC DC Switching Regulators
TSOT-23-8RoHSActive
High Efficiency Fast Response, 3A, 40V Input Synchronous Step Down Regulator
- Manufacturer
- Silergy
- Manufacturer part #
- SY8303AAIC
- Store part #
- C2937216
- Package / case
- TSOT-23-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
19,707 in stock
#C2937216
Stock & price checked 18 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹92.80 | ₹92.80 |
| 10+ | ₹77.79 | ₹777.90 |
| 30+ | ₹67.16 | ₹2,014.80 |
| 100+ | ₹58.68 | ₹5,868.00 |
| 500+ | ₹52.59 | ₹26,295.00 |
| 1,000+ | ₹50.86 | ₹50,860.00 |
1 × ₹92.80
₹92.80
excl. GST
₹109.50 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SY8303AAIC
₹92.80 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+105℃@(TA)
- Frequency - Switching
- 500kHz~2.5MHz
- Number of Outputs
- 1
- Function
- Step-down type
- Features
- Cycle-by-cycle current limiting;Light load efficient mode
- Topology
- Buck
- Output Type
- Adjustable
- Operating Voltage
- 4.5V~40V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 3A
- Quiescent Current
- 19uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.046 g
Overview
The SY8303A develops a high efficiency synchronous step-down DC/DC converter capable of delivering 3A load current. The SY8303A operates over a wide input voltage range from 4.5V to 40V and integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss. The SY8303A adopts peak current control scheme. The switching frequency is adjustable from 500 kHz to 2.5MHz using an external resistor. The device also features ultra low quiescent operating to achieve high efficiency under light load. And the internal soft-start limits inrush current during power on. SY8303A is available in TSOT23-8 package.
Applications
- LCD-TV
- SetTop Box
- Notebook
- Storage
- High Power AP Router
- Networking
Key features
- Low RDS(ON) for Internal Switches (Top/Bottom): 110/70 mΩ
- 4.5 - 40V Input Voltage Range
- Internal Compensation
- Internal 1ms Soft-start Limits the Inrush Current
- Adjustable Switching Frequency Range: 500 kHz to 2.5MHz
- 3A Output Current Capability
- 1.5% 0.6V Reference
- Low Quiescent Current
- Cycle-by-cycle Peak Current Limitation
- Short Circuit Protection
- Thermal Shutdown and Auto Recovery
- RoHS Compliant and Halogen Free
- Compact Package: TSOT23-8
