TechcodeDatasheet (PDF)
TD1660
200kHz Step-down type Adjustable 800mV~52V 2A ESOP-8 Voltage Regulators - DC DC Switching Regulators
ESOP-8RoHSActive
60V/2A Step-Down Converter
- Manufacturer
- Techcode
- Manufacturer part #
- TD1660
- Store part #
- C2832211
- Package / case
- ESOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,180 in stock
#C2832211
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹99.97 | ₹99.97 |
| 10+ | ₹80.84 | ₹808.40 |
| 30+ | ₹71.28 | ₹2,138.40 |
| 100+ | ₹61.72 | ₹6,172.00 |
| 500+ | ₹46.50 | ₹23,250.00 |
| 1,000+ | ₹43.46 | ₹43,460.00 |
1 × ₹99.97
₹99.97
excl. GST
₹117.96 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
TD1660
₹99.97 for 1 + GST
Specifications
- Operating Temperature
- -40℃~+125℃@(TJ)
- Frequency - Switching
- 200kHz
- Function
- Step-down type
- Number of Outputs
- 1
- Features
- Cycle-by-cycle current limiting;Light load efficient mode;External compensation;Frequency synchronization
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 60V
- Switch tube (built-in/external)
- Built-in
- Output Voltage
- 800mV~52V
- Output Current
- 2A
- Quiescent Current
- 180uA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.16 g
Overview
The TD1660 is a high frequency step-down switching regulator with integrated internal highside high voltage power MOSFET. It provides 2A output with current mode control for fast loop response and easy compensation. The wide 9V to 60V input range accommodates a variety of step-down applications, including those in automotive input environment. A 1μA shutdown mode supply current allows use in battery-powered applications. High power conversion efficiency over a wide load range is achieved by scaling down the switching frequency at light load condition to reduce the switching and gate driving losses. The frequency foldback helps prevent inductor current runaway during startup and thermal shutdown provides reliable, fault tolerant operation. The TD1660 is available in ESOP8 package.
Applications
- High Voltage Power Conversion
- Automotive Systems
- Industrial Power Systems
- Distributed Power Systems
- Battery Powered Systems
Key features
- Wide 9V to 60V Operating Input Range
- 250mΩ Internal Power MOSFET
- Up to 1MHz Programmable Switching Frequency
- 180μA Quiescent Current
- Ceramic Capacitor Stable
- Internal Soft-Start
- Up to 95% Efficiency
- Output Adjustable from 0.8V to 52V
- Available in ESOP8 PbFree Package
