TDSEMIC

TL431-0.5%

Shunt Voltage Reference IC Adjustable 2.5V~36V ±0.5% 100mA SOT-23

SOT-23ROHS CompliantActive

Three-terminal adjustable shunt regulator

Manufacturer: TDSEMIC
Manufacturer part #: TL431-0.5%
Store part #: C25503866
Package / case: SOT-23
Category: Voltage Reference
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

30,520 in stock

#C25503866

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
20+	₹4.99	₹99.80
200+	₹3.86	₹772.00
600+	₹3.24	₹1,944.00
3,000+	₹2.87	₹8,610.00
9,000+	₹2.54	₹22,860.00
21,000+	₹2.37	₹49,770.00

Quantity (min 20, multiples of 20)

20 × ₹4.99

₹99.80

excl. GST

₹117.76 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TL431-0.5%

₹99.80 for 20 + GST

Specifications

Output Voltage: 2.5V~36V
Tolerance: ±0.5%
Voltage - Supply: 2.5V~36V
Minimum Cathode Current for Regulation: 80uA
Reference Type: Parallel
Output Current: 100mA
Operating Temperature: -25℃~+125℃
Output Type: Adjustable

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 20 (multiples of 20)
Unit weight: 0.037 g

Overview

The TL431 is a three-terminal adjustable shunt regulator with guaranteed thermal stability over a full operation range. It features sharp turn-on characteristics, low temperature coefficient and low output impedance, which make it ideal substitute for Zener diode in applications such as switching power supply, charger and other adjustable regulators. The output voltage of TL431 can be set to any value between Vref (2.5V) and the corresponding maximum cathode voltage (36V). This IC is available in 2 packages: T0-92 and S0T-23. The TL431 is a three-terminal adjustable shunt regulator with guaranteed thermal stability over the full operating temperature range. It features fast turn-on, low temperature drift, and low output impedance, making it an ideal replacement for Zener diodes in switching power supplies, chargers, and other adjustable regulator applications. Output voltage range: Vref (2.5V) to maximum cathode voltage (36V). Packages: T0-92 and S0T-23.
