UMW

TL431(0.5%)

2.495V~36V ±0.5% 100mA Adjustable TO-92 Voltage Reference RoHS

TO-92ROHS CompliantActive

Adjustable Precision Shunt Regulator

Manufacturer: UMW
Manufacturer part #: TL431(0.5%)
Store part #: C351448
Package / case: TO-92
Category: Voltage Reference
Packaging: Bag-packed

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

5,510 in stock

#C351448

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹6.30	₹63.00
100+	₹4.95	₹495.00
300+	₹4.27	₹1,281.00
1,000+	₹3.55	₹3,550.00
5,000+	₹3.14	₹15,700.00
10,000+	₹2.94	₹29,400.00

Quantity (min 10, multiples of 10)

10 × ₹6.30

₹63.00

excl. GST

₹74.34 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 1,000 per bag

TL431(0.5%)

₹63.00 for 10 + GST

Specifications

Output Voltage: 2.495V~36V
Tolerance: ±0.5%
Minimum Cathode Current for Regulation: 500uA
Reference Type: Parallel
Output Current: 100mA
Operating Temperature: -40℃~+85℃
Output Type: Adjustable

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Bag-packed
Standard pack: 1,000 / Bag
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.176 g

Overview

UMW TL431 is a series of three-terminal adjustable voltage regulators with guaranteed thermal stability over the operating temperature range. The output voltage can be set to any value between Vref and 36V using two external resistors. The device features a typical dynamic output impedance of 0.27Ω, and the active output circuit provides very sharp turn-on characteristics, making it an excellent replacement for Zener diodes in many applications.
