TECH PUBLICDatasheet (PDF)
TPE4106RS6
14VC Clamp TVS DIODE SOT-23-6
SOT-23-6RoHSActive
TVS DIODE 5.5VWM 14VC SOT-23-6
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TPE4106RS6
- Store part #
- C2841428
- Package / case
- SOT-23-6
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,980 in stock
#C2841428
Stock & price checked 13 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹26.55 | ₹132.75 |
| 50+ | ₹23.48 | ₹1,174.00 |
| 150+ | ₹22.17 | ₹3,325.50 |
| 500+ | ₹20.55 | ₹10,275.00 |
| 3,000+ | ₹17.42 | ₹52,260.00 |
| 6,000+ | ₹16.99 | ₹1,01,940.00 |
5 × ₹26.55
₹132.75
excl. GST
₹156.64 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TPE4106RS6
₹132.75 for 5 + GST
Specifications
- Clamping Voltage
- 14V
- Peak Pulse Power Dissipation (Ppp)
- 50W@8/20us
- Voltage - Breakdown
- 8.5V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 10nA
- Reverse Stand-Off Voltage (Vrwm)
- 5.5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.036 g
Overview
Applications
- Glucose Meter
- Tablets
- GPS Portable Media Players
Key features
- Ultra low capacitance: 0.6pF typical 1/O to GND
- Ultralow leakage: nA level
- Low operating voltage: 5.5V
- Uni-directional TVS Diode Array
- Low clamping voltage
- Complies with following standards:
- IEC 61000 - 4 - 2 (ESD) immunity test Air discharge: ±20kV Contact discharge: ±15kV
- IEC61000 - 4 - 5 (Lightning) 3.3A (8/20μs)
- IEC61000 - 4 - 4 (EFT) 80A (5/50ns)
- ROHS Compliant
