TECH PUBLIC

TPG4735YJ

1.5V~5.5V 2 3.3Ω QFN-16L(2x2.6) Analog Switches, Multiplexers, Demultiplexers RoHS

QFN-16L(2x2.6)ROHS CompliantActive

Manufacturer: TECH PUBLIC
Manufacturer part #: TPG4735YJ
Store part #: C49333114
Package / case: QFN-16L(2x2.6)
Category: Analog Switches, Multiplexers, Demultiplexers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,875 in stock

#C49333114

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹146.68	₹146.68
10+	₹121.25	₹1,212.50
30+	₹107.35	₹3,220.50
100+	₹91.49	₹9,149.00
500+	₹84.54	₹42,270.00
1,000+	₹81.27	₹81,270.00

Quantity (min 1)

1 × ₹146.68

₹146.68

excl. GST

₹173.08 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TPG4735YJ

₹146.68 for 1 + GST

Specifications

Features: Bidirectional analog channel;Power-off isolation
Operating Temperature: -40℃~+85℃
Voltage - Supply: 1.5V~5.5V
Number of Channels: 2
Ron: 3.3Ω
Con: 7pF

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 1 g

Overview

This device is a bidirectional, low-power, dual-port, high-speed USB 2.0 analog switch with integrated protection for USB Type-C systems. It is configured as a dual 4:1 or 1:4 switch. The device is optimized for use with USB 2.0 DP/DM lines in USB Type-C systems. It features low bit-to-bit skew and high channel-to-channel noise isolation, and is compatible with multiple standards such as high-speed USB 2.0 (480 Mbps). Each switch is bidirectional with minimal or no attenuation of high-speed signals at the output. The bandwidth is wide enough to transmit high-speed USB 2.0 differential signals (480 Mb/s) with good signal integrity.
