TPS631012YBGR

The TPS631012 and TPS631013 are constant-frequency peak current mode buck-boost converters in a miniature wafer-level chip-scale package. With a 3A (typical) peak current limit and an input voltage range of 1.6V to 5.5V, they provide power solutions for system pre-regulators and voltage regulators. Depending on the input voltage, the TPS631012 and TPS631013 automatically operate in boost, buck, or 3-cycle buck-boost mode when the input voltage is approximately equal to the output voltage. Transitions between modes occur at defined duty cycles, avoiding unnecessary switching within a mode to reduce output voltage ripple. A quiescent current of 8μA and a power-save mode enable maximum efficiency under light-load to no-load conditions. In a WCSP package, these devices offer an extremely small solution size.

Applications

• TWS
• System pre-regulator (smartphones, tablets, terminals, telematics)
• Point-of-load regulation (wired sensors, port/cable adapters and converters)
• Fingerprint, camera sensors (smart electronic locks, IP network cameras)
• Voltage regulator (data communications, optical modules, cooling/heating)

Key features

• Input voltage range: 1.6V to 5.5V
• Device input voltage at startup > 1.65V
• Output voltage range: 1.0V to 5.5V (adjustable)
• High output current capability, 3A peak switching current
• IOUT = 2A when VIN ≥ 3V, VOUT = 3.3V
• IOUT = 1.5A when VIN ≥ 2.7V, VOUT = 3.3V
• High efficiency across full load range
• Typical quiescent current: 8μA
• Configurable automatic power-save mode and forced PWM mode
• Peak current buck-boost mode architecture
• Seamless mode transition
• Forward and reverse current operation
• Supports startup into pre-biased output
• Fixed-frequency operation at 2MHz switching frequency
• Safe and reliable operating features
• Overcurrent protection and short-circuit protection
• Integrated soft-start with active ramp
• Overtemperature protection and overvoltage protection
• True shutdown with load disconnect
• Forward and reverse current limiting
• Default settings for internal EN
• TPS631012 and TPS631012X (X = 1, 2, 3): CONVERTER_EN = 0
• TPS631013: CONVERTER_EN = 1
• Small solution size
• 1µH small inductor
• WCSP package size: 1.803mm × 0.905mm
