TECH PUBLICDatasheet (PDF)
TPTVS12VS1UR
19.9V 20.1A@10/1000us 400W@10/1000us 14.7V Unidirectional 12V SOD-123FL TVS Diodes
SOD-123FLRoHSActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- TPTVS12VS1UR
- Store part #
- C52145941
- Package / case
- SOD-123FL
- Category
- TVS Diodes
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,660 in stock
#C52145941
Stock & price checked 9 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.02 | ₹80.20 |
| 100+ | ₹6.31 | ₹631.00 |
| 300+ | ₹5.45 | ₹1,635.00 |
| 3,000+ | ₹4.80 | ₹14,400.00 |
| 6,000+ | ₹4.30 | ₹25,800.00 |
| 9,000+ | ₹4.04 | ₹36,360.00 |
10 × ₹8.02
₹80.20
excl. GST
₹94.64 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TPTVS12VS1UR
₹80.20 for 10 + GST
Specifications
- Clamping Voltage
- 19.9V
- Operating Temperature
- -55℃~+150℃
- Peak Pulse Current (Ipp)
- 20.1A@10/1000us
- Peak Pulse Power Dissipation (Ppp)
- 400W@10/1000us
- Number of Channels
- 1
- Voltage - Breakdown
- 14.7V
- type
- TVS
- Polarity
- Unidirectional
- Reverse Leakage Current (Ir)
- 500nA
- Reverse Stand-Off Voltage (Vrwm)
- 12V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.041 g
Overview
Transient Voltage Suppression (TVS) diodes are widely used in consumer electronics, automotive, telecommunications, and intelligent control systems.
Applications
- Consumer electronics
- Automotive industry
- Telecommunications
- Intelligent control systems
