TECH PUBLIC

TPWSP6580Q-16

2 200mΩ 3.3V~4.5V QFN-16L(1.8x2.6) Analog Switches, Multiplexers, Demultiplexers

QFN-16L(1.8x2.6)RoHSActive

High Fidelity Stereo SPDT Switch with Pop and Click Elimination

Manufacturer: TECH PUBLIC
Manufacturer part #: TPWSP6580Q-16
Store part #: C48886843
Package / case: QFN-16L(1.8x2.6)
Category: Analog Switches, Multiplexers, Demultiplexers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,581 in stock

#C48886843

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹74.09	₹74.09
10+	₹66.27	₹662.70
30+	₹62.37	₹1,871.10
100+	₹58.45	₹5,845.00
500+	₹56.06	₹28,030.00
1,000+	₹54.76	₹54,760.00

Quantity (min 1)

1 × ₹74.09

₹74.09

excl. GST

₹87.43 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TPWSP6580Q-16

₹74.09 for 1 + GST

Specifications

Features: Glitch-free switching
Operating Temperature: -40℃~+85℃
Number of Channels: 2
Ron: 200mΩ
Voltage - Supply: 3.3V~4.5V
Con: 30pF

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.095 g

Overview

This device is a dual SPDT analog switch designed for specialized stereo audio applications handling negative-swing audio signals, featuring ultra-low distortion and high off-state isolation. The typical on-resistance is only 0.2Ω at 3.3V VCC. The device operates from a wide single-supply range of 3.0V to 4.5V, is compatible with 1.8V logic levels, and offers a high power supply rejection ratio. Each signal pin incorporates a dedicated pop-suppression shunt circuit to eliminate popping under various operating conditions, including switching, enable/disable, power-down, and power-up. With exceptional THD+N performance and other high-performance specifications, this device is an ideal choice for high-fidelity system applications.
