TX4113
Buck Switching Regulator IC Adjustable 1 Output 2A SOT23-6
SOT23-6ROHS CompliantActive
2A, 4.5V-16V Input, 600kHz Synchronous Buck Converter
- Manufacturer
- XDS
- Manufacturer part #
- TX4113
- Store part #
- C5382729
- Package / case
- SOT23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,670 in stock
#C5382729
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹21.29 | ₹106.45 |
| 50+ | ₹16.68 | ₹834.00 |
| 150+ | ₹14.71 | ₹2,206.50 |
| 500+ | ₹12.25 | ₹6,125.00 |
| 3,000+ | ₹11.15 | ₹33,450.00 |
| 6,000+ | ₹10.50 | ₹63,000.00 |
5 × ₹21.29
₹106.45
excl. GST
₹125.61 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
TX4113
₹106.45 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Function
- Step-down type
- Frequency - Switching
- 600kHz
- Number of Outputs
- 1
- Features
- Light load efficient mode;Cycle-by-cycle current limiting;Hiccup current limiting;Overcurrent Protection
- Output Type
- Adjustable
- Topology
- Buck
- Operating Voltage
- 4.5V~16V
- Switch tube (built-in/external)
- Built-in
- Output Current
- 2A
- Quiescent Current
- 400uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.045 g
Overview
TX4113 is a fully integrated, high-efficiency 2A synchronous rectification buck converter driver IC. TX4113 operates efficiently across a wide output current load range. The device offers two operating modes — PWM control and PFM mode switching control — achieving high efficiency over a wide load range. TX4113 requires minimal external components. Available in a compact SOT23-6 package.
Applications
- Distributed power systems
- Digital set-top boxes
- Flat panel TVs and monitors
- Wireless and DSL modems
- Notebook computers
Key features
- High efficiency: up to 96%
- 600KHz operating frequency
- 2A continuous output current
- No Schottky diode required
- 4.5V to 16V wide input voltage range
- 0.6V reference voltage
- Slope compensation current mode control
- Excellent line and load transient response
- Integrated internal compensation
- Low ESR ceramic output capacitor compatible
- Overcurrent protection with hiccup mode and thermal shutdown
- Inrush current limiting and soft start
- SOT23-6 package
- -40°C to +85°C temperature range
