DDF

U211B-SOP-16

F/V 14.6V~16.6V SOP-16 V/F and F/V Converters

SOP-16RoHSActive

Manufacturer: DDF
Manufacturer part #: U211B-SOP-16
Store part #: C53199176
Package / case: SOP-16
Category: V/F and F/V Converters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,782 in stock

#C53199176

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
1+	₹149.02	₹149.02
10+	₹122.93	₹1,229.30
30+	₹108.54	₹3,256.20
100+	₹92.46	₹9,246.00
500+	₹85.16	₹42,580.00
1,000+	₹82.03	₹82,030.00

Quantity (min 1)

1 × ₹149.02

₹149.02

excl. GST

₹175.84 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,000 per reel

U211B-SOP-16

₹149.02 for 1 + GST

Specifications

Operating Temperature: -10℃~+85℃
Linearity: ±1%
Vos - Input Offset Voltage: 10mV
Conversion Type VF/FV: F/V
Voltage - Supply: 14.6V~16.6V
Ib - Input Bias Current: 10nA;600nA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.32 g

Overview

The U211B integrated circuit is designed using bipolar technology as a phase control circuit with a built-in frequency-to-voltage converter. The device incorporates an internal control amplifier, making it suitable for motor applications requiring speed regulation. In addition, the device integrates load limiting, speed monitoring, and soft-start functions to enable sophisticated motor control systems.
