UNI-SEMIC

U8063

Boost Switching Regulator IC Adjustable 2.5V~28V 1 Output 3.5A SOT-23-6L

SOT-23-6LROHS CompliantActive

2A High Efficiency Boost DC/DC Voltage Regulator

Manufacturer: UNI-SEMIC
Manufacturer part #: U8063
Store part #: C41374771
Package / case: SOT-23-6L
Category: Voltage Regulators - DC DC Switching Regulators
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,430 in stock

#C41374771

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹31.17	₹155.85
50+	₹27.11	₹1,355.50
150+	₹25.36	₹3,804.00
500+	₹23.18	₹11,590.00
3,000+	₹22.21	₹66,630.00
6,000+	₹21.63	₹1,29,780.00

Quantity (min 5, multiples of 5)

5 × ₹31.17

₹155.85

excl. GST

₹183.90 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

U8063

₹155.85 for 5 + GST

Specifications

Operating Temperature: -40℃~+80℃@(TA)
Frequency - Switching: 1.2MHz
Function: Boost
Number of Outputs: 1
Features: Light load efficient mode;Overcurrent Protection
Output Type: Adjustable
Topology: Boost
Operating Voltage: 2V~24V
Switch tube (built-in/external): Built-in
Output Current: 3.5A
Output Voltage: 2.5V~28V
Quiescent Current: 90uA

Packaging & compliance

RoHS: ROHS Compliant
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.045 g

Overview

A miniature, high-efficiency boost DC/DC regulator. The circuit consists of a current-mode PWM control loop, error amplifier, slope compensation circuit, comparator, and power switch. The IC operates efficiently and stably over a wide load range, with an integrated 4A power switch and soft-start protection circuit. Up to 93% conversion efficiency effectively extends battery life. The output voltage is set by adjusting two external resistors.
