VBM2309
P-Channel 30V 70A 50W Through Hole ITO-220AB-3
ITO-220AB-3RoHSActive
MOSFET P-CH 30V 70A ITO-220AB-3
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- VBM2309
- Store part #
- C481025
- Package / case
- ITO-220AB-3
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
7 in stock
#C481025
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹95.61 | ₹95.61 |
| 10+ | ₹77.65 | ₹776.50 |
| 50+ | ₹63.08 | ₹3,154.00 |
| 100+ | ₹54.30 | ₹5,430.00 |
| 500+ | ₹48.91 | ₹24,455.00 |
| 1,000+ | ₹46.12 | ₹46,120.00 |
1 × ₹95.61
₹95.61
excl. GST
₹112.82 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
VBM2309
₹95.61 for 1 + GST
Specifications
- Operating Temperature
- -55℃~+150℃
- Drain to Source Voltage
- 30V
- Current - Continuous Drain(Id)
- 70A
- Ciss-Input Capacitance
- 3.95nF
- Pd - Power Dissipation
- 50W
- Reverse Transfer Capacitance (Crss)
- 390pF
- RDS(on)
- 8mΩ@10V
- Number
- 1 P-Channel
- Gate Charge(Qg)
- 57nC@10V
- Gate Threshold Voltage (Vgs(th))
- 2.5V
- Type
- P-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.71 g
Overview
Applications
- Load Switch
- Notebook Adapter Switch
Key features
- Halogen-free
- Trench power MOSFET
- 100% gate resistance (Rg) tested
- 100% unclamped inductive switching (UIS) tested
- RoHS compliant
