X2510WRS-04-9TSN
Connector Header 4 position 2.54mm Pitch 4A Surface Mount, Right Angle
SMD,P=2.54mm,Surface Mount,Right AngleRoHSActive
CONN HEADER SMD R/A 4POS 2.54mm
- Manufacturer
- XKB Connection
- Manufacturer part #
- X2510WRS-04-9TSN
- Store part #
- C908468
- Package / case
- SMD,P=2.54mm,Surface Mount,Right Angle
- Category
- Headers, Male Pins
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
330 in stock
#C908468
Stock & price checked 8 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹33.82 | ₹169.10 |
| 50+ | ₹27.02 | ₹1,351.00 |
| 150+ | ₹24.09 | ₹3,613.50 |
| 500+ | ₹18.23 | ₹9,115.00 |
| 2,500+ | ₹16.62 | ₹41,550.00 |
| 5,000+ | ₹15.64 | ₹78,200.00 |
5 × ₹33.82
₹169.10
excl. GST
₹199.54 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 500 per reel
X2510WRS-04-9TSN
₹169.10 for 5 + GST
Specifications
- Connector Type
- Surface Mount, Right Angle
- Voltage Rating (Max)
- 250V
- Contact Material
- Brass
- Number of PINs Per Row
- 4
- Number of Rows
- 1
- Pitch
- 2.54mm
- Flame Retardant Rating
- UL94V-0
- Current Rating
- 4A
- Supplementary Features
- Auxiliary Solder Pin
- Number of PINs
- 4P
- Contact Plating
- Tin
- Operating Temperature
- -25℃~+85℃
- Plastic Material
- PA9T
- Color
- Creamy-White
- X-Length of Bottom Edge on Board (Spacing Line)
- 12.7mm
- Pin Structure
- 1x4P
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.904 g
