XLSEMI

XL3001E1

LED Driver IC 1 Output DC-DC Buck PWM Dimming SOIC-8-EP

SOIC-8-EPRoHSActive

Switching current step-down LED constant current driver

Manufacturer: XLSEMI
Manufacturer part #: XL3001E1
Store part #: C73020
Package / case: SOIC-8-EP
Category: LED Drivers ICs
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

6,310 in stock

#C73020

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹58.29	₹291.45
50+	₹43.88	₹2,194.00
150+	₹37.64	₹5,646.00
500+	₹29.90	₹14,950.00
2,500+	₹26.46	₹66,150.00

Quantity (min 5, multiples of 5)

5 × ₹58.29

₹291.45

excl. GST

₹343.91 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

XL3001E1

₹291.45 for 5 + GST

Specifications

Features: Over Voltage Protection;Short Circuit Protection;Over-Temperature Protection (OTP)
Frequency - Switching: 220kHz
Switch Tube (Built-In/External): Built-in
Operating temperature: -40℃~+125℃
Topology: Buck
Number of Channels: 1
Type: DC-DC
Output Current: 3A
Voltage - Input(DC): 8V~40V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.146 g

Overview

XL3001 is a step-down constant-current LED driver operating over a DC 8V to 40V input voltage range, featuring low ripple and an integrated power MOS. XL3001 incorporates a fixed-frequency oscillator and frequency compensation circuit, simplifying circuit design. The PWM control loop regulates the duty cycle with linear adjustment from 0 to 100%. Built-in output overcurrent protection reduces switching frequency from 220KHz to 60KHz under output short-circuit conditions. An internal compensation module minimizes external component count.
