SAEDatasheet (PDF)
1RC0603F2324
2.32MΩ 100mW 75V Thick Film Resistor ±100ppm/℃ ±1% 0603 Chip Resistor - Surface Mount
0603RoHSActive
- Manufacturer
- SAE
- Manufacturer part #
- 1RC0603F2324
- Store part #
- C54531304
- Package / case
- 0603
- Category
- Chip Resistor - Surface Mount
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
9,300 in stock
#C54531304
Stock & price checked 3 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 100+ | ₹0.2911 | ₹29.11 |
| 1,000+ | ₹0.2249 | ₹224.90 |
| 5,000+ | ₹0.1852 | ₹926.00 |
| 10,000+ | ₹0.172 | ₹1,720.00 |
| 50,000+ | ₹0.1455 | ₹7,275.00 |
100 × ₹0.2911
₹29.11
excl. GST
₹34.35 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 5,000 per reel
1RC0603F2324
₹29.11 for 100 + GST
Specifications
- Resistance
- 2.32MΩ
- Power(Watts)
- 100mW
- Voltage Rating
- 75V
- Type
- Thick Film Resistor
- Temperature Coefficient
- ±100ppm/℃
- Tolerance
- ±1%
- Operating Temperature
- -55℃~+155℃
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 5,000 / Reel
- Sold per
- Piece
- Minimum order
- 100 (multiples of 100)
- Unit weight
- 0.023 g
Overview
Key features
- Compact size, lightweight
- Reduced assembly cost, compatible with pick-and-place machines
- Suitable for wave soldering and reflow soldering
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 0603WAF2324T5E#C407533UNI-ROYAL · 0603 | UNI-ROYAL | 0603 | 4,300 | ₹0.1455 · 4,300 in stock | View |
 | RC0603FR-072M32L#C482791YAGEO · 0603 | YAGEO | 0603 | 3,200 | ₹1.43 · 3,200 in stock | View |
| CRCW06032M32FKEA#C2085713VISHAY · 0603 | VISHAY | 0603 | On request | Price on request | Quote | |
| RMCF0603FT2M32#C2481700SEI(Stackpole Electronics Inc.) · 0603 | SEI(Stackpole Electronics Inc.) | 0603 | On request | Price on request | Quote | |
| RCS1608F2324CS#C3957958Samsung Electro-Mechanics · 0603 | Samsung Electro-Mechanics | 0603 | On request | Price on request | Quote | |
