50N06
N-Channel 60V 60A Surface Mount TO-252
TO-252RoHSSold out at source
MOSFET N-CH 60V 60A TO-252
- Manufacturer
- VBsemi Elec
- Manufacturer part #
- 50N06
- Store part #
- C3040334
- Package / case
- TO-252
- Category
- Single FETs, MOSFETs
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
27 in stock
#C3040334
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹104.79 | ₹104.79 |
| 10+ | ₹85.64 | ₹856.40 |
| 50+ | ₹69.07 | ₹3,453.50 |
| 100+ | ₹59.68 | ₹5,968.00 |
| 500+ | ₹53.90 | ₹26,950.00 |
| 1,000+ | ₹51.11 | ₹51,110.00 |
1 × ₹104.79
₹104.79
excl. GST
₹123.65 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 50 per tube
50N06
₹104.79 for 1 + GST
Specifications
- Output Capacitance(Coss)
- 570pF
- Ciss-Input Capacitance
- 4.2nF
- Pd - Power Dissipation
- 136W
- Operating Temperature
- -55℃~+175℃
- Drain to Source Voltage
- 60V
- Current - Continuous Drain(Id)
- 60A
- Reverse Transfer Capacitance (Crss)
- 325pF
- RDS(on)
- 13mΩ@4.5V
- Number
- 1 N-channel
- Gate Charge(Qg)
- 47nC@10V
- Vgs
- ±20V
- Gate Threshold Voltage (Vgs(th))
- 3V
- Type
- N-Channel
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Sold out at source
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 2.72 g
Overview
Applications
- Mobile computing applications
- Load switch
- Notebook adapter switch
- DC/DC converter
Key features
- 175 °C Junction Temperature TrenchFET Power MOSFET
- N-Channel MOSFET
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | VBE1615B#C967494VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 9 | ₹98.62 · 9 in stock | View |
 | FDD24AN06L_F085-VB#C45350934VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 10 | ₹116.25 · 10 in stock | View |
 | IPD30N08S2L21ATMA1-VB#C45662340VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 10 | ₹116.25 · 10 in stock | View |
 | STD35NF06T4-VB#C46527824VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 10 | ₹116.25 · 10 in stock | View |
 | 2SK3402-AZ-VB#C45350920VBsemi Elec · TO-252 | VBsemi Elec | TO-252 | 10 | ₹116.25 · 10 in stock | View |
