5499160-6

Pop-up latch omitted from this view for clarity. See view S-S. For tables and notes, see page 2. 1. Dimensional coordinates apply from the basic position. 2. 10-pin and 14-pin versions include only one slot for a snap-in polarizer (polarization), located as shown. 3. 10-pin version includes only one slot for dual polarization, located as shown. 4. Recommended PCB thickness is 1.57 [0.062]. 5. Distance required by the ejector latch in the open position. Housing and latch are glass-filled nylon or polyester, UL94V-0 rated; color per table. Contacts: phosphor bronze or brass. Contacts: in the selectively plated area, minimum gold over palladium-nickel plating thickness 0.76μm [0.00030]; solder tail minimum tin plating thickness 2.54μm [0.00100]; overall contact minimum nickel underplate thickness 1.27μm [0.000050]. Alternatively, in the selectively plated area, minimum gold plating thickness 0.76μm [0.000030]; solder tail minimum tin plating thickness 2.54μm [0.00100]; overall contact minimum nickel underplate thickness 1.27μm [0.000050]. Datums M and N are determined by the customer.
