XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,100 in stock
HLDatasheet (PDF)
6206A33
3.3V Positive Fixed SOT-23-3L Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOT-23-3LROHS CompliantActive
300mA, Low Dropout Linear Regulator
- Manufacturer
- HL
- Manufacturer part #
- 6206A33
- Store part #
- C23377923
- Package / case
- SOT-23-3L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
8,400 in stock
#C23377923
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹2.22 | ₹111.00 |
| 500+ | ₹1.75 | ₹875.00 |
| 3,000+ | ₹1.40 | ₹4,200.00 |
| 6,000+ | ₹1.24 | ₹7,440.00 |
| 24,000+ | ₹1.11 | ₹26,640.00 |
| 51,000+ | ₹1.03 | ₹52,530.00 |
50 × ₹2.22
₹111.00
excl. GST
₹130.98 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
6206A33
₹111.00 for 50 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Ta)
- Supply Current (Iq)
- 6uA
- Output Configuration
- Positive
- Output Current
- 300mA
- Operating Voltage
- 6V
- Features
- Short Circuit Protection;Over Current Protection;Thermal shutdown
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.001 g
Overview
The HL6206A33 Series are highly precise, low power consumption, 3 terminal, positive voltage regulators manufactured using CMOS technologies. The HL6206A33 Series consists of a current limiter circuit a driver transistor, a precision reference voltage and an error correction circuit The series is compatible with low ESR ceramic capacitors. The current limiter's foldback circuit operates as a short circuit protection as well as the output current limiter for the output pin.
Applications
- Mobile Phones
- Battery powered equipment
- Portable game consoles
- Reference voltage sources
Key features
- Quiescent Current: 6μA
- Input Voltage Range: Max: 6V
- Output Current: 300mA
- Low Dropout Voltage: 180mV@100mA
- Output Voltage: 3.3V
- Output Voltage Accuracy: ±2% (Typ.)
- Low Power Consumption
- Available Packages: SOT23 - 3
